The PI‑SG565D (QuecPi PI‑SG565D) is a high‑performance single‑board computer (SBC) by Quectel for AIoT, edge computing, robotics, industrial control, multimedia, and other data‑intensive embedded applications. It offers desktop‑class performance in a compact, open SBC with versatile I/O and strong multimedia/networking capabilities.
Features:
- Processor / Compute:
- Qualcomm QCS6490, 8‑core 64‑bit processor delivering up to 12,15 TOPS, with Adreno‑642L / 643 GPU
- Memory & Storage:
- 8 GB LPDDR4X RAM. 128 GB UFS (default), upgradable to 256 GB. Supports external eMMC or SSD
- Networking & Wireless:
- Dual‑band WiFi (2,4 GHz & 5 GHz, IEEE 802.11 a/b/g/n/ac), Bluetooth 5.0, Gigabit Ethernet
- I/O Interfaces:
- USB‑C power
- 1 × PCIe interface
- Multiple USB ports
- Raspberry Pi 40‑pin compatible GPIO extension header
- SD card expansion
- Debug UART (“DBG_UART”) for serial console
- Operating System / Software:
- Supports Linux (Ubuntu, Yocto). Fully open-source hardware/software. UART root login by default. Dev tools and docs via QuecDevZone
- Lifecycle Support:
- Supported through approx. 2036
Product benefits:
- With 12–12,5 TOPS in the SBC/edge‑AI category, the board surpasses many low-end SBCs reliant on smaller ARM cores or lacking GPU/AI acceleration.
Applications:
- Smart city, industrial process control, advertising, AI, medical
