Most Popular Connector Family - Universal MATE-N-LOK

The universal series from TE Connectivity consists of Soft Shell connectors in a 6.35 mm grid with many possible combinations for correct connection, especially with a larger number of connectors in the application. A waterproof version is available, as well.
This is an archive article published 05/28/2021. Some information may no longer be up to date and in line with the current state. Please contact us in case of interest.

Most Popular Connector Family - Universal MATE-N-LOK
The Universal MATE-N-LOK series of connectors was developed decades ago, but its popularity has not declined over the years; on the contrary, it is finding its application in an increasing number of industries.

Robust and Reliable

Universal MATE-N-LOK connectors utilize a combination of pins and sockets intermixed in the plug and cap housings to achieve excellent electrical performance in a 6,35mm pitch design.

The nominal voltage is 600VAC/VDC, and the current is 19A. There are wire-to-wire, wire-to-panel, and wire-to-board configurations available. Housings feature positive polarization, positive locking, and rear cavity identification for easy, error resistant assembly. Contacts are enclosed in the housings and are removable for system flexibility.

Universal MATE-N-LOK connectors offer numerous options, including circular, flanged, bulkhead, sealed, and coloured housings in various materials (including Glow Wire compliant) to offer solutions for many diverse applications.

Most Popular Connector Family - Universal MATE-N-LOK
Features/benefits of the
Universal MATE-N-LOK system:

  • Pins and sockets can be intermixed in the same housing
  • Positive polarization
  • Rear cavity identification
  • Contacts completely enclosed in housings
  • Positive locking housings
  • Removable, crimp snap-in contacts
  • Low contact mating force
  • Contacts accept 0,05-5 mm2 wire sizes
  • Contacts available with tinned or gold plating
  • Panel mount or free-hanging
  • Mate with Universal MATE-N-LOK II Housings
  • Available in UL 94V-O flame-retardant material
  • Not for interrupting current
  • Harness to PC Board capability using pin or socket headers
  • Pin and socket headers are available in both vertical and right-angle style
  • Contacts are on .250 [6.35] centerline spacing

Please, use the terminology provided here to specify your inquiries.

Basic terms and features of the family are provided in the next figure:

Possible versions:

Most Popular Connector Family - Universal MATE-N-LOK

Most Popular Connector Family - Universal MATE-N-LOK

Existing applications utilizing Universal MATE-N-LOK connectors can be upgraded to a splash-proof system using connector Wire Seal an Interface Seal.

The connector seals are designed to ensure a water-resistant seal between mated plug and cap housings. One interface seal, two-wire seals, and optional sealing plugs are required per assembly.

Main features of the splash-proof solution:

  • Economical splash proof/ immersible sealed connector system
  • No design changes to the existing Universal MATE-N-LOK product
  • Utilizes two-wire seals and one interface seal
  • Wire range is 0,5-2,0mm2 with insulation diameter range 1,52-3,30mm
  • 2,79-3,30mm insulation diameter passed European IP sealing level 5/6 + 7 (swirling dust/ immersion to 1 meter for 30 minutes)
  • 1,52-2,79mm insulation diameter passed European IP sealing level 5/5 + 7 (swirling dust/ heavy seas)
  • Universal MATE-N-LOK II keying plug can be used to seal unused circuits
  • The primary application is for wire-to-wire; the wire-to-board application must use a closed bottom header

Typical wire-to-wire application:

Most Popular Connector Family - Universal MATE-N-LOK

The basic model of wire-to-wire connectors are stock types at SOS electronic.

In case of interest for other TE Connectivity connectors, do not hesitate to contact us at sales@soselectronic.com
