OPTOELECTRONICS AND SOUND/DISPLAYS/TFT MODULES - WL0F0007000A8GXACSA00
TFT-LCD Development Board with STM32H7 7,0" 1024x600 LAN, CANFD, RS485, RS232, UART, I2C, USB
na magazynie 0 szt
(Sprawdzamy termin dostawy: 2 szt)
Nr artykułu: 474976
1 szt+
679,04 Zł
Rabaty ilościowe
Wyślij zapytanie
7-inch multi-interface smart TFT module with STM32H
Features:
- Display: 7 inch, 1024×600 pixels, IPS, 85/85/85/85 viewing angles
- Interfaces: LAN, CAN FD, RS485, RS232, UART, I2C, USB
- Touch panel: capacitive
- Brightness: 850 cd/m²
- Operating voltage: DC 8~48 V
- Memory: 16 MB onboard flash for fonts, images, and UI data; optimised for ST's TouchGFX GUI
- GPIO: 16 configurable I/O pins (2,54 mm pitch) for custom device control
- Buzzer: integrated for feedback and system alerts
- Buttons: 3 user-configurable, inculding reset
- Status LEDs: power and SWD debugging indicators (SWDIO, SWCLK)
- Battery coin cell connector: supports RTC or low-power backup
- Input voltage: 8–48 V DC, suitable for industrial power sources
- SWD debug port: 4-pin (2,54mm) for firmware upload and real-time debugging
Product benefits:
- STM32H747 dual-core MCU: combines Cortex®-M7 and M4 processors for multitasking and advanced GUI performance
- 7.0" TFT display (WF70A8TYAHLNGB#): 850-nit brightness for outdoor readability
- PCAP panel: Projected capacitive touchscreen for responsive, modern user experience
Applications:
- Higher-level industrial equipment
- Suitable for commercial systems
